Parker Denison T6 Range

The Parker Denison T6 vane pumps from the T6CCM range have been specially designed for high/low circuits. The combination of different cartridges in double and triple pumps allows low flow at high pressure (300 bar max.) and high flow at lower pressure. This is a clever way to optimize your circuit design. This pump feature will also allow a very fast pressure cycle change with a very precise flow repeatability. Displacements range from Size A : 5,8 to 40,0 ml/rev. Size B : 5,8 to 50,0 ml/rev. Size C : 10,8 to 100,0 ml/rev. Size D : 44,0 to 158,0 ml/rev. Size E : 132,3 to 268,7 ml/rev. For the pressure cabability Size A : up to 300 bar max. Size B : up to 320 bar max. (300 bar for multiple pump). Size C : up to 275 bar max. Size D : up to 280 bar max. (250 bar for multiple pump). Size E : up to 240 bar max.

GET A QUOTE
denison hydraulics denison motor
  • Overview
  • Tech Specifications
  • Product Support

The T6 has high pressure capability up to 4650 PSI, in the small envelope, reduces installation costs and provides extended life at reduced pressure. The high volumetric efficiency, typically better than 94%, reduces heat generation, and allows speeds down to 600 RPM at full pressure. The high mechanical efficiency, typically better than 94%, reduces energy consumption. The wide speed range (600 RPM at 3600 RPM), combined with large size cartridge displacements will optimize operation for the lowest noise level in the smallest envelope. The low ripple pressure (± 29 PSI) reduces piping noise and increases lifetime of other components in the circuit. The high resistance to particle contamination, because of the double lip vane, increases pump life.
